| Model | YL-SM3500 |
| Capacity (kg) | 3500 |
| Wheelbase (mm) | 717 |
| Services Weight (with battery) (kg) | 400 |
| Protection Class | Machine IP44 |
| Tires | Solid Rubber |
| Universal Wheel | Polyurethane (PU) |
| Tire Size, Front (mm) | Ø250x86 |
| Tire Size, Rear (mm) | 200 |
| Overall length (mm) | 900 |
| Overall Width (mm) | 752 |
| Ground Clearance (mm) | 40 |
| Hook Clamping Height (mm) | 630-1200 |
| Hook Type | Maunal |
| Max. Travel Speed (km/h) | 5 |
| Services Brake | Electromagnetic |
| Drive Motor Rating S2 60 min (V/kw) | 36/1.2 |
| Battery Voltage, Nominal Capacity (V/Ah) | 3x12/80Ah |
| Type of Drive Control | DC-Speed Control |
| Sound Level at Driver’s Ear Acc. to EN dB(A) | <70 |
| Climbing Ability | <36.4% |
| Wheel Shield | Optional |
| Alarm Lamp | Optional |
| Model | YL-SM3500 |
| Capacity (kg) | 3500 |
| Wheelbase (mm) | 717 |
| Services Weight (with battery) (kg) | 400 |
| Protection Class | Machine IP44 |
| Tires | Solid Rubber |
| Universal Wheel | Polyurethane (PU) |
| Tire Size, Front (mm) | Ø250x86 |
| Tire Size, Rear (mm) | 200 |
| Overall length (mm) | 900 |
| Overall Width (mm) | 752 |
| Ground Clearance (mm) | 40 |
| Hook Clamping Height (mm) | 630-1200 |
| Hook Type | Maunal |
| Max. Travel Speed (km/h) | 5 |
| Services Brake | Electromagnetic |
| Drive Motor Rating S2 60 min (V/kw) | 36/1.2 |
| Battery Voltage, Nominal Capacity (V/Ah) | 3x12/80Ah |
| Type of Drive Control | DC-Speed Control |
| Sound Level at Driver’s Ear Acc. to EN dB(A) | <70 |
| Climbing Ability | <36.4% |
| Wheel Shield | Optional |
| Alarm Lamp | Optional |
