| Model | CLY35A | CLY35B | CLY35C | |
| Load capacity | kg | 3500 | 3500 | 3500 |
| Apply to pallet | Double Pallet | Single Pallet | Single Pallet | |
| Wheel base | mm | 2084 | 1602 | 1602 |
| Operating type | Rider | Rider | Walkie | |
| Wheels | ||||
| Wheels type | PU | PU | PU | |
| Wheel quantity | 1/4/2 | 1/4/2 | 1/4/2 | |
| Driving wheel/ | ||||
| Balance wheel/ | ||||
| Bearing wheel | ||||
| Driving wheel size | mm | ￠228×93 | ￠228×93 | ￠228×93 |
| Balance wheel size | mm | ￠84×152 | ￠84×152 | ￠84×152 |
| Bearing wheel size | mm | ￠115×55 | ￠115×55 | ￠115×55 |
| Demension | ||||
| Min.fork lowered height | mm | 85 | 85 | 85 |
| Max.fork lifting height | mm | 230 | 230 | 230 |
| Max.lifting height | mm | 145 | 145 | 145 |
| Overall fork width | mm | 680 | 680 | 680 |
| Fork length | mm | 2432 | 1212/1365/1517 | 1212/1365/1517 |
| Fork width | mm | 250 | 230 | 230 |
| Fork thickness | mm | 60 | 60 | 60 |
| Overall length | mm | 3605 | 2374 | 2222 |
| Overall width | mm | 930 | 930 | 832 |
| Overall height | mm | 1536 | 1536 | 1536 |
| (With handle) | ||||
| Overall height | mm | 1280 | 1280 | 1280 |
| (Without handle) | ||||
| Min.Turning radius | mm | 2708 | 2190 | 2051 |
| Min.Aisle width for | mm | 3650 | 2536 | 2365 |
| pallets 1200×1200 | ||||
| Performance | ||||
| Travel speed, | km/h | 11/14 | 11/14 | 4/4.5 |
| laden/unladen | ||||
| Lift speed,laden/unladen | mm/s | 30/35 | 30/35 | 30/35 |
| Travel speed, | mm/s | 45/40 | 45/40 | 45/40 |
| laden/unladen | ||||
| Gradeability, | % | 5/12 | 5/12 | 5/12 |
| laden/unladen | ||||
| Electrical configuration | ||||
| Drive motor | KW | AC 4.2 | AC 4.2 | AC 3.0 |
| Lift motor | KW | DC 2 | DC 2 | DC 2 |
| Steering motor | KW | DC0.15 | DC0.15 | DC0.15 |
| Battery | V/Ah | 24/360 or FAAM 330/490 | 24/360 or FAAM 330/490 | 24/360 or FAAM 330/490 |
| Brake | Electromagnetic /Regenerative | Electromagnetic/ Regenerative | Electromagnetic/ Regenerative | |
| Controller | CURTIS | CURTIS | CURTIS | |
| Weight | ||||
| Battery weight | kg | 400 | 400 | 400 |
| Service weight with | kg | 1120 | 1045 | 910 |
