Economic range but reliable.
New design to meet norm EN1570:1999.
New hydraulic system increases safety and protects your goods,tepless rate fo lowering system remains irrespective of the weight of the load.
| Model | Capacity | Table Size | Table Height | Handle Height | Over Size | Net Weight |
| kg | LXW (mm) | H(Min/Max)(mm) | h(mm) | BXC(mm) | (kg) | |
| AS20 | 200 | 700x450 | 265/755 | 980 | 450x870 | 44 |
| AS30 | 300 | 852x502 | 330/910 | 1100 | 502x1050 | 74 |
| AS50 | 500 | 852x502 | 390/910 | 1100 | 502x1050 | 81 |
| AS80 | 800 | 920x520 | 442/1000 | 1130 | 520x1170 | 114 |
| AS35D | 350 | 920x520 | 435/1500 | 1130 | 520x1170 | 125 |
