Stainless Lift Table BSS

Quantity:

All made of stainless steel.

Conforms to EN1570 and ANSI / ASME safety standard.

Safety clearance between scissors to prevent from trapping.

Swivel wheel with protection frame and brake to prevent foot from injury.


Built-in relief valve to fulfill overload protection.

For use in food industry, medicine industry.

4

Model BSS10 BSS20 BSS30 BSS50 BSS75
Capacity(kg) 100 200 300 500 750
Min.Height(mm) 265 330 330 435 442
Max.Height(mm) 755 910 910 1000 1000
Platform Size(mm) 700×450 830×500 830×500 1010x520 1010x520
Wheel Size(mm) 100 125 125 150 125
Overall Size(mm) 950×450×1000 1010×500×1000 1010×500×1000 1158x520x1000 1260×520×1000
Net Weight(kg) 40 78 80 118 137
